1.5" Front Strut Spacer & 2" Rear Shackle Lift Kit for Hilux N70 05-14

PRODUCT OVERVIEW

This suspension lift kit is designed to raise the front and rear of compatible Toyota Hilux N70 models. It includes front coil strut spacers and rear extended greasable shackles to improve ground clearance, level stance and off-road performance.

KEY FEATURES – FRONT COIL STRUT SPACERS

• 25 mm front strut spacers providing approximately 1.5" (35–38 mm) lift*
• Built to strict OEM specification standards
• Suitable for use with standard or aftermarket suspension
• Helps correct typical nose-down stance on many 4x4 vehicles
• Quality tested with warranty support

KEY FEATURES – REAR EXTENDED SHACKLES

• Rear extended lift-up greasable shackles
• Built to strict OEM specification standards
• Provide approximately 2" (45–48 mm) rear lift*
• Improved ride comfort on and off-road as shackles move with the leaf springs
• Stepped bolt design helps prevent overtightening and bushing deformation
• Additional rear lift achieved by raising one end of the leaf spring
• Quality tested with warranty support

SPECIFICATIONS

• Front spacer thickness: 25 mm
• Approximate front lift: ~1.5" (35–38 mm)*
• Approximate rear lift: ~2" (45–48 mm)*
• Lift spacer is not a 1:1 ratio – control arm geometry multiplies lift vs spacer thickness
• Quality certifications: ROHS; ISO/TS16949; ISO9001:2008

PACKAGE CONTENTS

• 2 × 25 mm front strut spacers
• 2 × rear extended lift-up greasable shackles

FITMENT

Fitment information is based on the supplied data and should be confirmed against your vehicle before purchase.

• Fit for Toyota Hilux Vigo N70 4WD, model years 2005–2014**

INSTALLATION NOTES

• Professional installation is strongly recommended
• Installation guide or manual is not included
• *Actual lift height may vary depending on vehicle condition and fitted accessories
• Rear exhaust pipe may contact the shackle; adjust exhaust routing to create clearance

**Always verify compatibility (year, drive type, and chassis code) with your specific vehicle before ordering.
