Front Wheel Bearing Hub Kit for Suzuki Swift RS415 EZ 1.5L 2004-2011

PRODUCT OVERVIEW

Front wheel bearing hub kit designed for Suzuki Swift RS415 EZ 1.5L (11/2004–01/2011) with attached wheel studs on the hub. Manufactured from premium steel with heavy-duty seals and OEM-grade components for quiet, smooth-running operation and long service life.

KEY FEATURES

• Premium steel hub and bearing for durability and reliability
• Precision engineered to OEM specifications for correct fitment
• Integrated ABS in the bearing (where applicable)
• Attached wheel studs on hub for straightforward installation
• Designed for smooth rolling performance and reduced noise

WHAT'S INCLUDED

• Bare front wheel hub with attached wheel studs
• Wheel bearing (assembly required)

SPECIFICATIONS

• Vehicle: Suzuki Swift RS415 EZ ZC21S 1.5L M15A FWD (11/2004–01/2011)
• Stud pattern: 4 stud PCD M12 x 1.5 @ 100mm
• Spline quantity: 25
• Wheel flange outer diameter: 120mm
• Wheel pilot diameter: 54mm
• Brake pilot diameter: 60mm
• Bare hub overall height: 72.5mm
• Height where bearing sits: 34.8mm
• Hub/bearing pilot diameter: 40mm
• Bearing ID: 40mm
• Bearing OD: 72mm
• Bearing width: 36mm
• Integrated ABS: Yes, in the bearing
• Note: Requires assembly with attached wheel studs on hub
• For models using hubs with screw-in wheel studs, refer to part WBH1808

WARRANTY

• 12 month / 20,000 km warranty on hub, bearing and components

INSTALLATION NOTES

• Professional installation is recommended
• Ensure compatibility with attached-stud hub type before purchase
