Right CV Axle Drive Shaft for Nissan X-Trail T31, Dualis J10, Qashqai J10 2.0L CVT

PRODUCT OVERVIEW

Right-hand CV axle drive shaft engineered for Nissan X-Trail T31, Dualis J10 and Qashqai J10 2.0L CVT applications. Manufactured to OEM-style specifications for reliable performance in FWD and AWD/4WD driveline systems.

KEY FEATURES

• Designed for right-hand side, CVT transmission FWD and AWD/4WD models
• Heat-treated chrome steel construction for strength and durability
• High-quality Neoprene dust boots with stainless steel clamps to resist contamination
• Premium moly grease for smooth operation at varying angles, speeds and high RPM
• OEM-style fitment with specified spline counts and shaft dimensions

VEHICLE FITMENT

Please confirm transmission type, drive configuration and shaft dimensions before purchase, as Dualis/Qashqai have multiple CV shaft variants. Extension shaft length from inside of bearing face: 301.5 mm.

• Nissan Dualis J10, Chassis: FBAJ10, JBAJ10 (Great Britain built), J10, KJ10 (Japan built), 2.0 MR20DE DOHC VVT FWD CVT (05/2007 - 01/2016). FWD, CVT only, FBAJ10 04/2010 onwards only. Includes sub-models Ti, Ti-L, ST, 20G, 20S, Cross Rider.
• Nissan Dualis J10, Chassis: FBNJ10, JBNJ10 (Great Britain built), 2.0 MR20DE DOHC VVT AWD CVT (05/2007 - 01/2016). AWD, CVT only, FBNJ10 04/2010 onwards only. Includes sub-models Ti, Ti-L, S.
• Nissan Qashqai J10, Chassis: FBAJ10 (Great Britain/Japan built), JBAJ10 (Great Britain built), 2.0 MR20DE DOHC VVT FWD CVT (04/2010 - 01/2016). CVT, models 04/2010 onwards only.
• Nissan X-Trail T31, Chassis: T31, TBAT31 (Japan built), 2.0L MR20DE DOHC VVT FWD CVT (08/2007 - 03/2015). FWD, CVT only. Includes sub-models ST, ST Limited Edition, ST-L, 20S, 20X, 20XTT, Axis.
• Nissan X-Trail T31, Chassis: NT31 (Japan built), 2.0L MR20DE DOHC VVT 4WD CVT (08/2007 - 03/2015). 4WD, CVT only. Includes sub-models 20S 4WD, 20ST 4WD, 20XT 4WD, 20XTT 4WD, Axis 4WD, Driving Gear 4WD.

TECHNICAL SPECIFICATIONS

• Position: Right-hand side
• Transmission: CVT
• Drive type: FWD / AWD / 4WD (as listed in fitment)
• Length (compressed): 942.5 mm
• Spline count – outer/wheel side: 29T
• Spline count – inner/diff side: 27T
• Bearing outer diameter on extension shaft: 62 mm
• Extension shaft bearing width: 20 mm
• Extension shaft length from inside of bearing face: 301.5 mm
• Outboard joint type: Ball
• Inboard joint type: Tripod
• Hub nut style: M24 x 1.5

WHAT'S INCLUDED

• 1 x Right-hand CV axle drive shaft assembly

WARRANTY

Covered by a 12 month / 20,000 km warranty on the CV driveshaft assembly. CV boots are warranted for 3 months from date of purchase. Warranty applies subject to correct installation and application as per the specified vehicle fitment.
