Starter Motor For Chevy 305 350 V8 Small / Big Block 153 / 168 Tooth Flywheels

Starter Motor For Chevy 305 350 V8 Small / Big Block 153 / 168 Tooth Flywheels

Technical Specifications

Product Description

Applications

for Chevy for GMC HD Mini Starter Motor 3HP 305 350 454

for Chevy-V8 Small Block, Big Block& V6 with A/T& M/T with 153 or 168 Tooth Ring Gear

for Chevrolet Small & Big Block 262-454 CID V6-V8, w/ AT or MT, w/ 153-Tooth or 168-Tooth Flywheel (up to 18:1 Compression Ratio)

OEM(s) Replaced: for Chevrolet, for GMC Motors, High Performance Starter Motor

Features

High Torque, High Output Gear Reduction Drive design spins your Engine over faster.

50% more Cranking Torque

Perfect for High Compression or Supercharged Engines.

Straight Bolt Mounting Plates, works with all 153 tooth or 168 tooth ring-gears on all small block and big block for Chevy V8 and for Chevy V6.

capable of cranking a 15:1 compression engine that is up to 700 cubic inches.

3HP MOTOR

Details

Material: Aluminum

Interchange Part Number: for 18493, for 18493N

Replacement for Pp106, Pe106, 91-25-1201

Type: 3HP

Tooth Flywheel: 153 and 168

Number of Teeth: 9

Voltage: 12V

Power: 2KW / 2.68HP

Rotation: CW

Starter Size: Mini Type

Gear OD: 0.988in / 25.1mm

Version: High Torque Version/3-Clocking Positions

Mtg Ear 1 Hole: 10mm Unthreaded

Mtg Ear 2 Hole: 10mm Unthreaded

Mtg Ear 3 Hole: 10mm Unthreaded

Mtg Ear 4 Hole: 10mm Unthreaded

Condition: 100 % Brand New and tested

Warranty: 5 Years

Package Includes: You will get exactly as shown as the picture above

Key Features:

High Performance

All Items Tested for Reliability, Durability and Performance, 100% computerized load and power testing, maximum output and optimal performance assured.

Installation Note:

To use this type of starter you must verify that it has three bolt holes on the starter pad. You will use two of the three holes to mount this starter but they must be straight across from each other to accept this starter. This starter cannot be installed if the two holes are staggered

(PS: Check your block for starter bolt pattern used, 454 blocks many times had a staggered bolt starter.)

Design

Easy to Install

100% Brand New Aftermarket Unit.Installs a new starter is easy as original parts. Strict tolerance testing. Match with your model. Quick and easy installation.
